| Pump type
Pump type |
Electric motor | Diesel Engine III | ||||||||
| Input speed: 1480 rpm | Pump speed: 375 (468 rpm) | Input speed: 1500 rpm | Pump speed: 375 (468) rpm | |||||||
| Rated Flow | Pressure (MPa) | Rated Flow | Pressure (MPa) | |||||||
| L/min | m³/h | 110 kW | 132 kW | 160 kW | L/min | m³/h | 140 kW | 176 kW (154 kW) | 220 kW | |
| RLB160-17 | 23 | 1.4 | 240 | 280 | – | (29) | 1.7 | – | (240) | 280 |
| RLB160-19 | 29 | 1.7 | 200 | 240 | 280 | (34) | 2 | – | (200) | 240 |
| RLB160-26 | 54 | 3.2 | 100 | 120 | 140 | 54 | 3.2 | 100 | 110 | 140 |
| RLB160-34 | 92 | 5.5 | – | – | 80 | 92 | 5.5 | – | – | 80 |
| RLB160-(65)* | 400 | 24 | – | – | 20 | 400 | 24 | – | – | 20 |
| RLB160-(72)* | 500 | 30 | – | – | 16 | 500 | 30 | – | – | 16 |
| Weight: 556 kg | Import: G1 1/2″ | Export: M24×1.5, 24° Cone, 1 1/8″-12UNF-2B |
| * Weight: 520 kg | Import: G3 | Export: ZG1 1/4″ |
